24V空調機組
系列/SERIES參數/Specification機型/Model24V駐車發電機組/24V vehicle generator set24V駐車發電機組電壓（V）Voltage24額定功率(kVA)/Rated frequency3勵磁方式/Excitation mode永磁/Permanent magnet油箱容量（L）/Capacity of fuel tank12.5機架類型/Frame type25方管/Round tube動力型號/Power modelCG173F起動方式/St
| 系列/SERIES | 參數/Specification | 機型/Model |
| 24V駐車發電機組/24V vehicle generator set | ||
| 24V駐車發電機組 | 電壓（V）Voltage | 24 |
| 額定功率(kVA)/Rated frequency | 3 | |
| 勵磁方式/Excitation mode | 永磁/Permanent magnet | |
| 油箱容量（L）/Capacity of fuel tank | 12.5 | |
| 機架類型/Frame type | 25方管/Round tube | |
| 動力型號/Power model | CG173F | |
| 起動方式/Start mode | 回彈式繩索起動或電起動/Rope start or electric start | |
| 動力類別/Power style | 單缸，風冷，四沖程，立式/Single cylinder,Water-cooled,Four stoke,Vertical type | |
| 缸徑/Cylinder bore | 73 | |
| 行程/Piston stroke | 59 | |
| 排量（L）//Displacement | 0.246937822 | |
| 壓縮比/Compression ration | 19 | |
| 轉速/Speed | 3600 | |
| 發動機功率/Engine power | 3.4 | |
| 機油容量（L）/Capacity of oil | 0.75 | |
| 標定點燃油耗（g/kw.h）/Fuel consumption | 280 | |
| 燃油牌號/Fuel number | 柴油：0#（夏）-10（冬）Fuel:0#（Summer),-10(Winter) | |
| 機油牌號/Oil number | SAE10W30(CD級以上) | |
| 可選配置/Optional configuration | 大油箱/Big fuel tank,自動控制，一鍵啟停，遙控啟動 | |
| 外形尺寸（長*寬*高）（mm）/Overall dimension | 335*392*422 | |
| 凈重/Net weight | 35 |
