CG6
系列參數(shù)機型CG6R(Z)175AR(Z)180水冷單缸柴油機動力類型/Power type單缸，水冷，四沖程，臥式/Single cylinder,Water-cooled,Four stoke,Horizontal type燃燒室型式/Combustion chamber type渦流（直噴）/Whirling (Direct injection)缸徑(mm)/Cylinder Bore767580行程(mm)/Piston stroke6580排量(L)/Displacement0.295&nbs
| 系列 | 參數(shù) | 機型 | ||
| CG6 | R(Z)175A | R(Z)180 | ||
| 水冷單缸柴油機 | 動力類型/Power type | 單缸，水冷，四沖程，臥式/Single cylinder,Water-cooled,Four stoke,Horizontal type | ||
| 燃燒室型式/Combustion chamber type | 渦流（直噴）/Whirling (Direct injection) | |||
| 缸徑(mm)/Cylinder Bore | 76 | 75 | 80 | |
| 行程(mm)/Piston stroke | 65 | 80 | ||
| 排量(L)/Displacement | 0.295 | 0.353 | 0.402 | |
| 壓縮比/Compression ratio | 22 | 20(18) | ||
| 額定轉(zhuǎn)速(rpm)/Rated speed | 3000 | 2600 | ||
| 額定功率(kw)/Rated power | 3.8 | 4.41 | 5.15 | |
| 額定功率(hp)/Rated power | 5.17 | 6.00 | 7.00 | |
| 最大功率( KW)/Max power | 4.18 | 4.85 | 5.67 | |
| 最大功率 (HP)/Max power | 5.68 | 6.60 | 7.70 | |
| 最大扭矩（N.m)/Max torque | 16.10 | 18.63 | 21.75 | |
| 最大扭矩點轉(zhuǎn)速（r/min）/Speed at Max torque point | 2250 | 1950 | 1950 | |
| 標定點燃油耗（g/kw.h）/Fuel consumption | 303 | 280.2(263.8) | 278.8(258.2) | |
| 起動方式/Start mode | 手搖或電起動/Hand start or eletric start | |||
| 燃油牌號/Fuel number | 柴油：0#（夏）-10（冬）Fuel:0#（Summer),-10(Winter) | |||
| 機油牌號/Oil number | SAE10W30(CD級以上) | |||
| 外形尺寸（長*寬*高）（mm）/Overall dimension | 486×255×352 | 589×341×463 | 625×341×463 | |
| 凈重（kg）Net weight | 43 | 68 | 75 | |
